Once you experience the easy wireless independence provided by the WL-20 series, you’ll never go back to using a standard cable again. With no worries about cable management, you’re able to move about freely while playing at home, jamming with friends, and performing on stage. During sound check at a gig, you can listen to your tone out front and dial in the best sound for your audience. And with the ability to roam and interact with other musicians, your live shows will be more dynamic and entertaining than ever.
If you play a guitar or bass with standard passive pickups (the most common pickup type), the WL-20 model is probably your best choice. It includes built-in cable tone simulation, which reproduces the natural capacitive effect that’s introduced when using a 10-foot/3-meter guitar cable with passive pickups. This effect rolls off the treble very slightly, giving you the warm tone you’re used to hearing with a normal cable.
Accessories
Owner’s Manual
Leaflet USING THE UNIT SAFELY
Transmitter
Micro USB cable for charging (*1)- *1: Use a standard USB AC adaptor (5 V/over 0.5 A) for charging.
Wireless Format
BOSS proprietary digital audio format
Wireless carrier frequency
2.4 GHz
Compatible Channels
14
(May vary due to local conditions)
Transmission Range
50 feet line-of-sight
(May vary due to local conditions)
Latency
2.3 ms
Dynamic Range
110 dB or greater
Frequency Response
20 Hz–20 kHz
Nominal Output Level
-10 dBu
Output Impedance
1 k ohm
Recommended Load Impedance
10 k ohms or greater
Indicators
POWER
RECEIVE
Connectors
Output plug: 1/4-inch TRS phone type
TRANSMITTER jack: 1/4-inch TRS phone type
DC IN 5 V port: USB Micro-B type
Power Supply
Rechargeable lithium-ion battery
Supplied from the DC IN 5 V port
Current Draw
During wireless operation: 60 mA
While charging: 500mA
Battery charging time
Charging only the receiver: Approximately 3 hours
Charging simultaneously with the transmitter: Approximately 4 hours
Expected battery life under continuous use
Approximately 10 hours
* These figures will vary depending on the actual conditions of use.
Width
87 mm
3-7/16 inches
Depth
25 mm
1 inches
Height
38 mm
1-1/2 inches
Weight
60 g
3 oz
Specifications-Transmitter
Nominal Input Level
-10 dBu (1 M ohm)
Indicator
BATTERY
Connectors
Input plug: 1/4-inch TRS phone type
DC IN 5 V port: USB Micro-B type
Power Supply
Rechargeable lithium-ion battery
Supplied from the DC IN 5 V port
Current Draw
350mA
Battery charging time
Approximately 3 hours
Expected battery life under continuous use
Approximately 12 hours
* These figures will vary depending on the actual conditions of use.
Width
87 mm
3-7/16 inches
Depth
22 mm
7/8 inches
Height
36 mm
1-7/16 inches
