- Effects channel with reverb, chorus and delay
- 3-Channel EQ for each track
- Compressor on inputs 1 and 2
- Create playlist of projects with Sequence Play
- 150 preloaded drum loops
- 3 Subpanels for connecting microphones, instruments or line level devices like keyboards, mixing boards and more
- 48V Phantom power for condenser microphones
- Inputs: 2
- Connectors: 2 XLR/TRS combo jacks (Balanced, XLR: 2 HOT / TRS: TIP HOT
- Input gain: +6 ~ +50 dB
- Input impedance XLR: 3.9 k ohm TRS: 3.9 k ohm/1 M ohm (when Hi-Z ON, INPUT 1 only)
- Phantom power: +48 V (switchable separately for INPUTS 1 and 2)
- Equivalent input noise: –121 dBu or less (IHF-A) at +50 dB/150 ohm input
- Frequency response: −1.0/+0.5 dB: 20 Hz – 20 kHz
Master Out
- Outputs: 1
- Connectors: 2 TRS phone jacks (balanced)
- Maximum output level: +14 dBu
- Output impedance: 200 oHm
Phones Output
- Connectors: 1 stereo 0.137″ (3.5mm) mini jack
- Maximum output level: 45 mW + 45 mW (into 32 ohm load)
- Output impedance: 10 ohm
Recorder
- Maximum simultaneous recording tracks: 2
- Maximum simultaneous playback tracks: 8
- Recording format: 44.1kHz, 16/24-bit, mono/stereo WAV
- Recording media: 4–32GB cards compatible with the SDHC specification 64–1TB cards compatible with the SDXC specification
Track Settings
- EQ High: 10 kHz, ±12 dB, shelving
- Middle: 2.5 kHz, ±12 dB, peaking
- Low: 100 Hz, ±12 dB, shelving
- Pan: L100 – R100
Effects
- Input Dynamics Comp/Limiter/Gate
- Patch memory effects 3 types can be used simultaneously
- 50 patch memories
- Guitar Lab supported
- Can be assigned and used as an insert (input) or send effect
- Dedicated send effects 10 types of spatial effects
Tuner
- Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
- CLICK (METRONOME)
- Time signatures 3/4, 4/4, 6/8
- Tempo range: 40.0–250.0 BPM
- Time signatures: 3/4, 4/4, 6/8
- Rhythm Loops
- Sound source format: PCM
- Number of loops: 150
Synth
- Sound source format: FM
- Polyphony: 8
- Number of sound types: 18 (and a PCM drum kit)
Display
- 2.4″ (320×240) full-color touchscreen LCD
USB
- Connector: USB Type-C
Audio Interface Function
- 2-in/2-out or 2-in/2-out (iPad) USB 2.0 Full Speed
- 44.1 kHz, 16/24-bit
- 2-in/4-out USB 2.0 High Speed
- 44.1 kHz, 16/24-bit
Mass Storage Function
- Device USB 2.0 High Speed (5 V/200 mA power supplied when host)
Guitar Lab Connection
- USB 1.1 Full Speed
DAW Connection (Control Surface)
- USB 1.1 Full Speed
Mass Storage Function
- Host USB 2.0 High Speed (5V/200 mA power supplied)
USB MIDI Keyboard Connection
- USB 1.1 Full Speed (5 V/200 mA power supplied)
Power
- Batteries: 4 AA (alkaline, lithium, or rechargeable NiMH)
- AC adapter: ZOOM AD-17 (5V/1.0A)
Estimated Continuous Operation Time Using Batteries
- (During playback with +48V off and 32 ohm headphone load)
- Alkaline batteries: about 5 hours
- NiMH batteries (1900 mAh): about 5 hours
- Lithium batteries: about 11 hours
